Pmise SM-01

Slimming

Pmise SM-01

  • 4 handpieces with different size for all areas' treatment.
  • Special designed of detachable roller and inner filter for easy cleaning.
  • Dual mono-polar RF handpieces for fat dissolving are better than Bi-polar, which effectively avoids skin burning and blister.
  • Combines the Mono-polar &Bi-Polar Radiofrequency (RF), Infrared Light, Vacuum and Mechanical Roller.
  • The precise heating of RF ensures safe, effective, fast treatment without downtime. Vacuum and specially designed rollers for the Mechanical Massage smooth the skin to facilitate safe and efficient heat energy delivery.

Overview

Pmise SM-01 is a multi-technology slimming machine built for professional body contouring, cellulite reduction, and skin tightening in clinics and aesthetic centers. It brings together monopolar radiofrequency (RF), infrared light, vacuum suction, and a mechanical roller in a single console, so an operator can treat the abdomen, thighs, buttocks, arms, and the face and neck with one system.

The unit ships with four interchangeable handpieces of different sizes, which lets a trained operator match the applicator to large body zones or to smaller areas such as the jawline. That makes it a practical fit for treatment rooms that want one device covering several service menu items rather than several single-purpose machines.

SM-01 sits in the Pmise Slimming line. Before you buy, our slimming machine buying guide explains how RF, vacuum, and light-based platforms differ in real clinic use.

How It Works

SM-01 combines mechanical and thermal action so heat energy reaches the fat layer safely. Vacuum suction draws the skin fold up between the applicator surfaces, which brings the target tissue closer to the energy source and helps keep the treatment comfortable. At the same time the mechanical roller kneads and lifts the tissue, an action the KB manual describes as promoting metabolism of wastes, stimulating micro-circulation, and smoothing the skin surface.

Radiofrequency supplies the controlled heating. The manual states RF warms skin tissue to roughly 5 to 15 mm depth, while the infrared light heats the more superficial layer to about 5 mm. Warming the tissue in this range is intended to raise enzyme activity so stored triglycerides are more readily released and cleared through normal metabolism and lymphatic drainage, and to help firm laxity. The dual monopolar RF handpieces deliver energy into the subcutaneous layer while spreading it more evenly, which the source material links to a lower risk of surface hot spots than narrow bipolar-only heating.

The infrared component uses a broad near-infrared band that tissue absorbs and converts to heat, supporting vessel dilation and blood and lymphatic flow in the treated zone. This light-plus-heat rationale rests on the established principle that tissue chromophores absorb specific wavelengths and convert that energy to localized heat, described in Anderson and Parrish's 1983 work on selective photothermolysis. Vacuum, massage, RF, and infrared act together rather than as separate steps.

Applications

SM-01 is professional equipment for non-invasive body shaping and skin firming. It suits day spas, medical aesthetic clinics, and distributors serving those markets. Typical applications:

  • Cellulite reduction and improvement of orange-peel skin texture
  • Body reshaping and contouring of the abdomen, waist, thighs, buttocks, and arms
  • Double chin reduction and face and neck lifting
  • Skin tightening and improvement of skin laxity and elasticity
  • Improvement of the appearance of stretch marks
  • Supportive body care after liposuction or after pregnancy, once cleared by a physician

Results build gradually over a course of sessions and vary by individual, body area, and lifestyle. The device is not a weight-loss cure and does not replace diet or exercise. Trained staff should screen each client against the manual's contraindications, which include pregnancy, cardiac pacemakers or other electronic implants, metal implants in the area, active infection or skin lesions, and other serious medical conditions.

Key Advantages

  • Four interchangeable handpieces of different sizes cover large body zones and finer facial areas from one console.
  • Combined vacuum, mechanical roller, RF, and infrared let a clinic offer contouring, cellulite, and tightening services on a single platform.
  • Dual monopolar RF handpieces spread heat more evenly through the subcutaneous layer, which the KB material links to a reduced risk of surface burns and blistering versus bipolar-only heating.
  • Detachable roller and inner air filter are designed for quick cleaning between clients and simpler maintenance.
  • Adjustable intensity for RF, vacuum, infrared, and roller speed lets operators tailor each session to the area and client.
  • Non-invasive workflow with no incisions fits standard clinic scheduling.

Specification

Handpieces4pcs
Roller Speed≤20r/min
RF Frequency2.64MHz
Vacuum Suction IntensityI-VIII adjustable
Vacuum Suction FrequencyI-IV adjustable
IR IntensityI-V adjustable
RF PowerI-X adjustable
Roller FrequencyI-IV adjustable
Handpiece TypeXF-I+, XF-VII+, XF-VIII, XF-IX
RF Power≤400W
IR Wavelength700-2000nm
IR Power20W
Negative Pressure Intensity≤ -0.09Mpa
Power SupplyAC200-240V 50-60HZ MAX 6A;
Net Weight30kg
Gross Weight40kg
Dimensions (after package)56x56x125cm3

FAQ

What areas and concerns is SM-01 used for?

It is used for non-invasive body contouring, cellulite reduction, and skin tightening. Common areas include the abdomen, waist, thighs, buttocks, and arms, plus the face and neck for double chin reduction and lifting. The four handpieces let an operator match applicator size to each zone. It suits laxity and orange-peel texture rather than large-scale weight loss.

How many sessions are typically needed?

Body contouring with RF and vacuum platforms is usually delivered as a course rather than a single visit, with maintenance sessions afterward. The exact number depends on the individual, the treated area, and lifestyle factors such as diet and activity. Because outcomes vary, a trained operator should assess each client and set realistic expectations first.

Is it safe, and are there people who should not be treated?

SM-01 is professional equipment for trained operators, and cooling is aided by the vacuum and roller action that keeps treatment comfortable. The manual lists contraindications, including pregnancy, cardiac pacemakers or electronic implants, metal implants in the treatment area, active infection or skin lesions, epilepsy, and other serious conditions. Every client should be screened before treatment, and jewelry removed from the area.

What training and warranty support come with the machine?

As a manufacturer, Pmise supplies operating documentation and application guidance so clinical staff can learn safe protocols and correct handpiece selection. Warranty terms, spare handpieces, and consumables such as air filters can be arranged for distributor and clinic orders. Contact our team for current warranty coverage, training options, and the parts package for your region. To compare RF with other body-contouring technologies, see our overview of cavitation, cryolipolysis, and RF.
